Technical reference
Procurement reference model: PTNYB120-27. Wire Size: 4/0 AWG; Color: Red; Terminal Insulation: Nylon. Confirm the supplied equivalent and its specifications before ordering.
| Selling unit | piece |
|---|---|
| Reference pack size | 1 · source pack reference |
| Wire Size | 4/0 AWG |
| Color | Red |
| Terminal Insulation | Nylon |
| Terminal Material | Tin-Plated Copper |
| T | 2.7mm (0.11") |
| L | 76.0mm (3.00") |
| F | 36.2mm (1.40") |
| E | 39.8mm (1.60") |
| W | 13.7mm (0.57") |
| D | 24.1mm (0.95") |
| D1 | 16.6mm (0.66") |
| Max Temperature Rating | 105 o C |
| Max Voltage Rating | 600 Volts |
| UL Recognized | No |
| CE Certified | Yes |
| RoHS Compliant | Yes |
Drawings and product details
