Technical reference
Procurement reference model: RD1-12. Wire Size: 22-16 AWG; Stud Size: 1/2" Stud; Color: Red. Confirm the supplied equivalent and its specifications before ordering.
| Selling unit | piece |
|---|---|
| Reference pack size | 1 · source pack reference |
| Wire Size | 22-16 AWG |
| Stud Size | 1/2" Stud |
| Color | Red |
| T | 0.75mm (.03") |
| L | 35.9mm (1.41") |
| F | 16mm (0.63") |
| E | 10.5mm (0.41") |
| W | 19.6mm (0.77") |
| D | 4.2mm (0.17") |
| D1 | 1.7mm (.07") |
| D2 | 13mm (.51) |
| Terminal Insulation | Vinyl |
| Terminal Material | Tin-Plated Copper |
| Max Voltage Rating | 105°C - 600 Volts |
| Max Electrical Current | 18AMP |
| UL Recognized | Yes |
| CE Certified | Yes |
| RoHS Compliant | Yes |
