Technical reference
Procurement reference model: FRSV1-180. Wire Range: 22-16 AWG; W: 0.01" (4.4mm); F: 0.33" (8.5mm). Confirm the supplied equivalent and its specifications before ordering.
| Selling unit | piece |
|---|---|
| Reference pack size | 100 · source pack reference |
| Wire Range | 22-16 AWG |
| W | 0.01" (4.4mm) |
| F | 0.33" (8.5mm) |
| L | 0.84" (21.4mm) |
| B | 0.40" (10.2mm) |
| D | 0.15" (4.0mm) |
| C | 0.06" (1.7mm) |
| Terminal Material | Brass |
| Insulation Material | Vinyl |
| Insulation Color | Red |
| Temperature Rating | 105 o C - 600 Volts |
| Max AMP Rating | 10 AMP |
| UL Recgonized | Yes |
| CE Certified | Yes |
| RoHS Compliant | Yes |
