Technical reference
Procurement reference model: HC0B. Size (LxWxH): 0.77 x 0.37 x 0.20"; Color: Black; H: 5.0mm (0.20"). Confirm the supplied equivalent and its specifications before ordering.
| Selling unit | piece |
|---|---|
| Reference pack size | 100 · source pack reference |
| Size (LxWxH) | 0.77 x 0.37 x 0.20" |
| Color | Black |
| H | 5.0mm (0.20") |
| L | 19.6mm (0.77") |
| W | 9.5mm (0.37") |
| T (Cable Tie Slot Width) | 5.2mm (0.20") |
| B (Fixed Hole Size) | 3.7mm (0.15") |
| Mounting | Screw Mounted |
| Material | UL Approved 94UV-2 Nylon |
| Environment | Indoor |
| Flammability (Fire Rating) | UL 94V-2 |
| Gamma Radiation | 1x10 Rads |
| Temp Rating | -400°F to 185°F (-240°C to 85°C) |
| UL Recognized | No |
| RoHS Compliant | Yes |
| CE Certified | Yes |
Drawings and product details
